ข้อมูลทางเทคนิค
| Current consumption RP432 KP RP432 KPP |
13.8V +/-10%, 48 mA typical/52 mA max. 13.8V +/-10%, 62 mA typical/130 mA max. |
| Main panel connection | 4-wire BUS, up to 300 m (1000 ft) from Main Panel |
| Dimensions | 153 x 84 x 28 mm (6.02 x 3.3 x 1.1 inch) |
| Operating temperature | -10°C to 55°C (14°F to 131°F) |
| Storage temperature | -20°C to 60°C (-4°F to 140°F) |
| Prox. RF frequency | 13.56MHz |
| Complies with EN 50131-3 Grade 2 Class II |
