ข้อมูลสินค้า
- Dual Technologies : Microwave & Passive Infrared
- Anti-Cloak™ Technology (ACT™)
- ครอบคลุมระยะสูงสุด 25m (83ft)
- ได้รับการรับรองมาตรฐาน EN50131-1 Grade 3
- Active IR Anti-Mask with separate relay
- Built-in EOL resistors, jumper selectable
- Flexible installation height up to 3.3 (10’10”)
- Creep zone ลำแสงตรวจจับแนวดิ่ง
- หลอดไฟ LED แสดงสถานะการทำงาน 3 สี
- High RF immunity 30V/m
- Anti-fluorescent interference signal processing
- ป้องกันการงัดแงะ (อุปกรณ์เสริม)
- Corridor lens (optional)
- Voltage requirements: 12Vdc Typ. 5Vdc – 16Vdc
- Current consumption: 3.5mA Typ. 5mA (Max)
- Relay contact rating: 16VDC 50mA (Max)
- Size: (LxWxD) 51.7 x 16 x 12mm (2″ x 0.63″ x 0.47″)
- Weight :60g (0.132 lb)
- Cable length: 1.5m (4.9ft)
- Operating temperature: 0°C to 60°C (32°F to 140°F)
- Storage temperature: -20°C to 60°C (-4°F to 140°F)
- IP rating: IP67
