ข้อมูลทางเทคนิค
| Specification | Value |
|---|---|
| Operating Voltage | 13.8V ±10% |
| Power consumption | 170 mA, 5W max. |
| Display | 8-inch IPS, Resolution 800×1280, Illumination 300 cd/m² |
| Type of touch screen | Capacitive touch, 5-point touch control supported |
| System | Android 7.1.2 |
| CPU | A83T Octa-core Cortex A7 |
| Memory | 1G DDR3M RAM, 8G EMMC Flash |
| Wi-Fi | 802.11 b/g/n 2.4 GHz |
| Bluetooth | BT 4.0, 2.4 GHz |
| Output Power | 20 dBm Max. |
| Operating Temperature | -10°C to 55°C (14°F to 131°F) |
| Speaker | 1 speaker, 8 Ohm/1W |
| Microphone | 1xmic |
| Connections | USB – Ixtype C USB Jack, RS-485-detachable terminal block |
| Tamper | 1x Tamper |
| Standard | EN50131-3, Grade 3 Environmental Class II, PD 6662:2017 |
