ข้อมูลทางเทคนิค
| Batteries : CR123A 3V x4 |
 |
| Smoke Alarm | Photoelectrical chamber with optical sensor for detecting smoke |
| Heat detector | 4 sensors for measuring temperature increase, alarm will be triggered at 60°C |
| Operating modes | Smoke + Heat (OR Logic), Only Smoke, Only Heat |
| Indicators | Audible (Piezo) and visual (LED) |
| Volume of the warning | Min. 85 dB at 3m (10′) |
| Sound frequency | 3.25 kHz |
| Standby power consum. | 0.02mA (typical) |
| Alarm power consum. | 100mA |
| Battery life | 4 years (typical) |
| Low battery threshold | 2.65 V |
| In event of low battery | One beep every 30 seconds |
| Operating temperature | 0°C to 55°C |
| Humidity during operation | 10% to 85% RH, no condensation or icing |
| Color | White |
| Dimensions (D x H) | Ø 133.8 x 50.2 mm (Ø 5.27 x 1.98′) |
| Weight | 360 g (net) |
| Supervision monitoring | 1-255 min. (user defined) |
| Wireless trans. Power | 10mW |
| Wireless range | Up to 300m (unobstructed) |
| Standards Compliance | EN14604:2005/AC:2008. 1134-CPR-186 |
| NOTE | Only the “Smoke Operation Mode” is approved to EN14604. |
