| Specifications | ||
| Power supply | 110 – 240V ~50 – 60Hz | |
| Power consumption | to 0.8W | |
| Operational temperature | 0 – 35°C | |
| Dimensions (L x W x H) | 42.50 x 38.25 x 20.30 mm | |
| For installation in boxes | Ø ≥ 50mm | |
| Rated load current | 10A for resistive load* | |
| Overcurrent protection | required external 10A circuit breaker | |
| Active element | micro-gap relay switch μ | |
| Device control | remotely – radio waves directly – push buttons |
|
| Radio protocol | Z-Wave | |
| Radio signal power | 1mW | |
| Radio Frequency | 868.4 MHz EU; 908.4 MHz US; 921.4 MHz ANZ; 869.0 MHz RU; 865.2 MHz IN; |
|
| Range | up to 50 m outdoors up to 30 m indoors (depending on building materials) |
|
| Comply with EU directives | RoHS 2011/65/EU RED 2014/53/EU |
| Technical Information |
||
|
